The LSI 9207-8i is an internal SAS/SATA host bus adapter built around the LSI SAS2308 controller. In IT-mode, it provides eight internal 6Gb/s SAS/SATA ports through two SFF-8087 mini-SAS connectors and connects to the host with a PCIe 3.0 x8 interface.
- Firmware mode: IT-mode
- IO controller: LSI SAS2308
- Storage connectivity: 8 ports, 6Gb/s SAS 2.1 compliant
- Supported link rates: 1.5Gb/s, 3.0Gb/s, 6.0Gb/s
- Host interface: x8 lane PCI Express 3.0 compliant
- Connectors: Two internal mini-SAS connectors (SFF-8087)
- Device support: Up to 256 non-RAID devices
- Bracket options: Full-height and low-profile
- Physical dimensions: 167.6-mm x 64.5-mm (6.6-in. x 2.54-in.)
- Nominal power: 9.8 W
